temperature range from 5°C above ambient to 250/300°C
characterized by noiseless operation and gentle sample heating in the chamber, offering high-quality and safe heating and drying of samples up to constant weight
high operation comfort, precise temperature control and short chamber temperature equalization times after the door opening
suitable for perfect drying of thermally labile and oxidation sensitive materials, complicated shapes, drying of samples to constant weight, etc. in vacuum
wide selection of optional equipment and accessories (e.g. supplementing the “Vacustation” base with the option of installing a selected type of a vacuum pump,…)
Product images are for illustrative purposes only and may differ from the actual product.
Safety thermostat class according to DIN 12880 (user adjustable)
The protective thermostat is used to protect the exposed material, the device itself and its surroundings in the event of an unexpected course of regulation or failure. The temperature in the chamber is measured and evaluated by an independent control block. When the limits of the protection thermostat are exceeded, the heaters are disconnected from the mains voltage and the heating of the cabinet is stopped.
Stainless steel shelf
Shelf made of stainless steel AISI 304, suitable for placing a small-size sample in the chamber.
Aluminium shelf
Aluminum shelves guarantee fast and efficient heat transfer to the samples
Door lock (same key for order)
Mechanical door lock for the basic level of protection. It is supplied with two keys.
Door lock (different keys for order)
Mechanical door lock for the basic level of protection. It is supplied. Within one set of devices, different lock inserts are distinguished.
Automatic door lock
The device is equipped with an electromagnetic mechanism for blocking-locking the door. Can be operated manually or automatically.
Stainless steel shell
Stainless steel design of the device housing, including AISI 304 stainless steel handle
Stainless steel interior DIN 1.4301/AISI 304
Standard chamber design made of stainless steel AISI 304 only the inner equipment of the chamber, the chamber always from DIN 1.4404/AISI 316L
Stainless steel interior DIN 1.4404/AISI 316L
Optional chamber design in stainless steel AISI 316 with higher chemical resistance only the inner equipment of the chamber, the chamber always from DIN 1.4404/AISI 316L
Flexible PT sensor
Additional movable sensor in the chamber for measuring the temperature at the sample or in the sample. It is not used for temperature control. The additional sensor data is shown on the display as an additional temperature value. (max. 4 pc)
Flexible PT sensor at the temperature of 300°C
Additional movable sensor for higher temperatures.
(consultation required)
Access port CF Ø 40 mm B
The port with a stainless steel body allows the wires, sensors, etc. to be threaded into the chamber. Ø 40 mm.
Access port - special shape or position
The port with a stainless steel body allows the wires, sensors, etc. to be threaded into the chamber. Optional size, shape or position in the wall. (consultation required)
Interior lighting
Heat-resistant interior lighting with mechanical switch.
Special housing modification for insulator technologies
A set of mechanical modifications of the device for tight connection to the laboratory insulator. (consultation required)
Modification without particles
Sealing of the chamber and fan to prevent particles from entering the chamber from the outside. (consultation required)
Vacustation
Painted cabinet in the design of the device for placing the pump, located under the Vacucell device of the given size. (except the volume 22)
Vacuum pump Vacubrandt MZ2CNT+AK+EK
Vacuum pump Vacubrandt MD4CNT+AK+EK
Vacuum pump on request
(consultation required)
Special electric access port
(Je potřeba konzultace)
Aggressive heating
Service functions allowing to increase or decrease start times. This function can change the properties of the device.
ECO PLUS
The optional extension for Eco devices expands the number of segments from 2 to 8 for one program and allows temperature ramps to be defined within the program.
Internal socket max. 100°C (230 V, 3 A protection, IP67)
The socket (nominal voltage 230 V, fuse 3 A, protection IP67) is located inside the chamber on the side wall. (consultation required)
The potential-free contact is connected to a connector to which voltages up to 24 V / 1 A can be connected. It is used to implement a remote alarm (in Anglo-Saxon countries it is referred to as BMS relay - Building Management System relay) - i.e. a remote line that is interrupted by a built-in relay potential-free contact, the fault information is transmitted to rooms other than the one in which the temperature box is located. The relay opens in all error states reported on the display.
Emergency stop button
Hardware main switch with a lockable system, which, if necessary, interrupts the connection of electric power. (consultation required)
National design of the electric plug
Power supply termination supply according to the national standard (consultation required)
Operation temperature shift
Increasing the maximum working temperature to 300 °C
Digital vacuum display (0.1-1100 mbar)
Analogue output 4-20mA
The device contains a converter of the required quantity (temperature, CO2 concentration) to a 4-20 mA output, connected to a connector connection. It is not a quantity read by the instrument itself and converted to 4-20 mA. The customer processes the value himself and must also ensure the calibration of the sensors. Data cannot be collected using WarmComm.
Software Warmcomm 4 Basic (B)
"WarmComm 4 is designed to record the course of device control. The program uses the Server - Client arrangement. In this configuration, the monitored devices are connected to a Server that records and stores data obtained during control. Individual users then access this data through the Client. This arrangement can be implemented within a single PC, within a LAN or via the Internet or within a local network."
Software Warmcomm 4 Professional (P)
"WarmComm 4 is designed to record the course of device control. The program uses the Server - Client arrangement. In this configuration, the monitored devices are connected to a Server that records and stores data obtained during control. Individual users then access this data through the Client. This arrangement can be implemented within a single PC, within a LAN or via the Internet or within a local network."
Software Warmcomm 4 FDA (F)
"WarmComm 4 is designed to record the course of device control. The program uses the Server - Client arrangement. In this configuration, the monitored devices are connected to a Server that records and stores data obtained during control. Individual users then access this data through the Client. This arrangement can be implemented within a single PC, within a LAN or via the Internet or within a local network."
External printer
Use the EPSON TM-T20III to print the report.
Software PrinterArchiv
The Printer Archive program is intended for recording from the machine's print output. It serves as a direct replacement for a physical printer. The recording is in a fixed, preset format. Wider options for handling the recorded protocol, including archiving or printing to a desktop PC printer. Ordinary PCs with Windows XP and higher operating software can handle the hardware requirements. One free RS 232 (COM) port is required for each connected device. The maximum length of the connecting cable is 15 m. For more detailed requirements towards HW, get information from the dealer.
Internal temperature measurement, 1 point
Validation of the temperature distribution in the chamber at the user's reference temperature (1 point).
Measurement of temperature distribution, 3 points
Validation of the temperature distribution in the chamber at the user's reference temperature (3 points).
Temperature measurement, 9-point (DIN 12880)
Validation of the temperature distribution in the chamber at the user's reference temperature (9 points).
Temperature distribution measurement, 27-point (DIN 12880)
Validation of the temperature distribution in the chamber at the user's reference temperature (27 points).
Validation documentation
IQOQ dokumentation
Ethernet communication port for ECO
Optional equipment extends the communication capabilities of ECO devices with Ethernet.
